The CM3 series moulded case circuit breaker (hereinafter referred to as the circuit breaker) has a rated working voltage up to 690V, rated insulation voltage of 800V, rated impulse withstand voltage up to 8kV, and rated current from 10A to 630A. The CM3 series circuit breaker is suitable for power distribution and motor protection applications, as well as fire protection applications. It has an overload alarm without tripping function. When the line is overloaded, the circuit breaker installed with this function does not trip but only outputs an overload signal, ensuring continuity of power supply, meeting the requirement of GB50054 Clause 4.3.5: "For lines where sudden power failure causes greater losses than overload, the overload protection should act on a signal rather than cutting off the circuit." The circuit breaker has overload, short-circuit, undervoltage protection and other functions, protecting lines and power supply equipment from damage.
The circuit breaker is divided into four types according to the rated ultimate short-circuit breaking capacity (Icu): Type C (basic), Type L (standard), Type M (higher breaking), and Type H (high breaking). This circuit breaker has the characteristics of small size, high breaking capacity, short arc distance (zero arc distance achieved by adding a zero arc shield). The product has a beautiful appearance and reasonable layout, and can be installed vertically (i.e., upright) or horizontally (i.e., side-mounted), making it an extremely ideal electrical product.
This circuit breaker has isolation function, and its corresponding symbol is The circuit breaker has obtained the national compulsory product certification "CCC" mark, and is a "China Famous Brand" and "National Exemption" product.
The CM3 series moulded case circuit breaker (hereinafter referred to as the circuit breaker) is developed after careful analysis of the needs of the power system. It absorbs the advantages of similar products, summarizes the experience of joint design products, fully considers the overall movement requirements of the equipment, as well as the safety and convenience of operators, and strives for reasonable design, while considering the completeness and universality of the equipment. It is one of the new types of circuit breakers developed using advanced international design and manufacturing technology. Its rated working voltage is up to 690V, rated insulation voltage is 800V, rated impulse withstand voltage reaches 8kV, and rated current is 10A~800A. The CM3 series circuit breaker is suitable for power distribution and motor protection applications, as well as fire protection applications. The circuit breaker can have an overload alarm without tripping function. When the line is overloaded, the circuit breaker installed with this function does not trip but only outputs an overload signal, ensuring continuity of power supply, meeting the requirement of GB50054 Clause 4.3.5: "For lines where sudden power failure causes greater losses than overload, the overload protection should act on a signal rather than cutting off the circuit." The circuit breaker has overload, short-circuit, undervoltage protection and other functions, protecting lines and power supply equipment from damage. The series moulded case circuit breaker can achieve protection coordination between upper and lower levels, with three-stage protection and isolation functions.
The CM3 series is available in two forms: short-circuit current protection (magnetic type) and overcurrent protection (thermal type). The circuit breaker has the characteristic of zero arc distance, especially suitable for compact drawer-type and enclosed switchgear assemblies. Its rated insulation voltage is 800V, suitable for AC 50Hz, rated working voltage up to 690V and below, and rated working current from 6A to 800A in circuits for overload, short-circuit, earth fault, and undervoltage protection of cables, transformers, engines, motors, etc., as well as for infrequent switching and infrequent starting of motors. It has two-stage non-selective and three-stage selective protection (above 225A). The circuit breaker has isolation function and complies with IEC60947-2 and GB14048.2 standards. The circuit breaker has obtained the national compulsory product certification "CCC" mark and is a "China Famous Brand" product.
Note: The above information and technical parameters are compiled and released by Yangzhou Dari Electric Co., Ltd.
