Product Aliases
Insulating Glove Withstand Voltage Test Device, Insulating Boot Glove Withstand Voltage Tester, Auxiliary Insulation Tool Test Device, Insulating Boot Insulating Glove Test Device
Product Features
1. Integrated high-voltage power supply and control system, easy wiring and operation, complete protection functions
2. Six test tanks, can test six insulating boots or gloves simultaneously
3. Six digital ammeters, intuitive leakage current, each meter has overcurrent automatic protection
4. Soft chain high-voltage electrode, electrode height can be adjusted arbitrarily
5. Electrode made of H62 copper material, surface plated with CU/EpNi5bc process to make surface discharge less than 10pC
Product Parameters
1. Rated capacity: 3kVA
2. Input voltage: AC220V±10% 50Hz±1
3. Output voltage: 0-30kV
4. Voltage accuracy: ≤2.5% (F.S)
5. Low voltage current: 0-15A
6. Leakage current: 0-10.0mA
7. Leakage current resolution: 0.1mA
8. Current accuracy: ≤2.0% (F.S)
9. Timing range: 0-999H
10. Ambient temperature: -20℃ to 50℃
Note: The above information and technical parameters are compiled and released by Yangzhou Dari Electric Co., Ltd.
