Product Introduction
After the test of the Wire Quality Tester - 300A High Current Generator is completed, the voltage regulator must be returned to zero, press the stop button to cut off the power supply, and cut off the working power before removing the test wiring to ensure safety.
Detailed Introduction
Usage of the Wire Quality Tester - 300A High Current Generator:
1. The instrument must be properly grounded.
2. Connect the power supply, turn on the switch, the red indicator light will be on, and the current generator is waiting to increase current.
3. Rotate the voltage regulator evenly clockwise, and pay attention to the output current indication on the operation panel until the required high current is reached.
4. During the test, once any abnormal phenomenon is found, cut off the power immediately, find out the cause, and then proceed with the test.
5. After the test, the voltage regulator must be returned to zero, cut off the power supply with the air switch, cut off the working power, and then remove the test wiring in the correct direction to ensure safety.
Product Description of Wire Quality Tester - 300A High Current Generator
The product adopts a split or integrated structure according to the output current size, and is relatively small in size and light in weight. This product also has the characteristics of stepless adjustment of output current, balanced current rise, wide load change range, reliable operation, simple operation, and safety. It is an ideal equipment for current rise or temperature rise tests.
It is specially designed and manufactured for electric power departments and industrial and mining enterprises to conduct current load tests and temperature rise tests on various switches, current transformers, and other electrical equipment in electrical equipment tests.
Structure Diagram:
1—Start button 2—Stop button
3—Current adjustment handle 4—Current switching
5—High current indication 6—Power indication
7—Low current indication 8—Voltage switching
9—Working indication 10—Voltage indication
11—High current output 12—Power input
