Real-time monitoring: The smart miniature circuit breaker works with a smart gateway to monitor key electrical parameters of the power line in real time, such as voltage, current, power, temperature, leakage, and energy consumption.
Remote control: Users can control the switch remotely via the smart gateway or mobile APP, anytime and anywhere.
Abnormal warning: When abnormal conditions occur on the power line, the smart miniature circuit breaker can issue a warning in time, effectively preventing fault escalation.
Short circuit protection: In the event of a short circuit, the smart miniature circuit breaker can quickly cut off the power supply to protect circuit safety.
Energy metering statistics: The smart miniature circuit breaker has energy metering and statistics functions, making it convenient for users to understand electricity usage.
Fault location: Through the smart gateway or mobile APP, users can quickly locate the fault point and perform timely maintenance.
Compact size with metering and control: The smart miniature circuit breaker is compact in size and has both metering and control functions, making installation and use convenient.
Multiple specifications available: According to different needs, the smart miniature circuit breaker is available in various specifications to meet various distribution requirements.
Strong compatibility: The smart miniature circuit breaker has strong compatibility and can work with most smart gateways on the market, facilitating intelligent upgrades for users.
Product Model | ASCB1-63 | ASCB1LE-63 | |
Number of Poles | 1P/2P/3P/4P | 2P/4P | |
Frame Size | 63A | ||
Rated Voltage | 230V (1P/2P), 400V (3P/4P) | ||
Rated Current | 6A,10A,16A,20A,25A,32A,40A,50A,63A | ||
Instantaneous Trip Type | C/D | ||
Rated Short-Circuit Breaking Capacity | 6000A | ||
Protection Functions | Overcurrent Protection | Default100% rated current warning, 110% rated current trip, threshold adjustable | |
Short Circuit Protection | ...
| ||
