XZD-3A Vibration Transmitter

Published: 2020-08-18 09:57:04

Category: Dynamic Balancing Measuring Instrument

Product Description

Dari Electric recommends

Main specifications of XZD-3A two-wire vibration transmitter:

1. Frequency response: 5 ～ 500 Hz

2. Measurement range: 0～50mm/s

3. Output current: 4～20mA

4. Output impedance: ≤500Ω

5. Operating voltage: DC24V

6. Maximum acceleration: 5g

7. Measurement accuracy: <±1% full scale

8. Measurement direction: vertical or horizontal

9. Dimensions: φ48×80 mm (later changed to φ42×80 mm)

10. Mounting thread: M10×1.5

11. Weight: approx. 250g

Brief description:

The XZD-3A two-wire vibration transmitter integrates the vibration sensor and precision measurement circuit into one unit, realizing the function of the traditional "sensor plus monitoring instrument" vibration measurement system, suitable for building economical high-precision vibration measurement systems.

Note: The above information and technical parameters are compiled and released by Yangzhou Dari Electric Co., Ltd.
