Product Introduction
It consists of a control part (low voltage) and high-voltage rectification, discharge, and testing sections. Sufficient safety space is reserved between high and low voltage, and between high/low voltage and the casing.
Technical Parameters:
1. Current and voltage: Single-phase AC 220V, 50Hz
2. DC output voltage for fault detection: 0—30KV (button control)
3. Cable fault detection accuracy: within ±50mm
4. Test output DC voltage: 0—30KV (button control)
5. Automatic withstand voltage test time: 0—30 minutes (settable)
6. Leakage current test range: 0—100 microamperes
7. Main transformer rated capacity: 3KVA
8. Rectification method: Single-phase half-wave
9. Discharge ball gap: handle screw adjustment
10. Dimensions: 1100×1000×1200mm (width×depth×height)
11. Weight: 85 Kg
Note: The above information and technical parameters are compiled and released by Yangzhou Darui Electric Co., Ltd.
